Product Summary

Finisar’s FTLX8571D3BNL Extended Temperature 10Gb/s SFP+ transceivers aredesigned for use in 10-Gigabit Ethernet and 10-Gigabit Fibre Channel links overmultimode fiber.They are compliant with SFF-8431310GBASE-SR/SWand 10G Fibre Channel 1200-Mx-SN-Ifunctions are available via a 2-wire serial interface, as specified in SFF-8472FTLX8571D3BCL is a “limiting module”, i.e., it employs a limiting receiver. Host boarddesigners using an EDC PHY IC should follow the IC manufacturer’s recommendedsettings for interoperability with an SFP+ limiting module. The transceiver is RoHScompliant and lead free per Directive 2002/95/EC72038

Parametrics

APPLICATIONS? 10GBASE-SR/SW 10G Ethernet? 1200-Mx-SN-I 10G Fibre Channel

Features

Hot-pluggable SFP+ footprint? Supports 9.95 to 10.5 Gb/s bit rates? Power dissipation < 1W? RoHS-6 compliant (lead-free)? Extended temperature range0°C to 85°C? Single 3.3Vpower supply? Maximum link length of 300m on2000 MHZ-km MMF? Uncooled 850nm VCSEL laser? Receiver limiting electricalinterface? Duplex LC connector? Built-in digital diagnostic functions

Diagrams
